Coding procedure
- Confirm entry with -Q- button.
Display on VAS5051:
- - Encoding is being performed
- Wait until next display appears.
Display on VAS5051:
- - Encoding performed in vehicle system
- - Control module identification with new code
(previous code in brackets)
- Exit function "07 - Encoding control module" by pressing --> button.
- Switch ignition off and then switch on again after 15 seconds.
NOTE:
- The next time the ignition is switched on the newly entered code will be activated.
- If the ignition is not switched off and on after the correct code has been entered, it will not be possible to erase DTC "01044 Control module incorrectly coded".
- In the case of non-hot country vehicles, the hot -country function (activation of the pump for coolant run -on) must be deactivated in function 11 - Login, or function 11 - Coding II. See HOT-COUNTRY FUNCTION, ACTIVATING / DEACTIVATING . After installation of the new control module, a DTC memory entry is made.
