Implementing function "04 - Basic setting"

Indicated on display:

Fig 1: V.A.G 1551 Scan Tool (ST) Display - Front Passenger Seat Adjustment With Memory Control Module, Basic Setting, Function 04 (1 Of 6)

Courtesy of AUDI OF AMERICA, INC.

Indicated on display:

Fig 2: V.A.G 1551 Scan Tool (ST) Display - Front Passenger Seat Adjustment With Memory Control Module, Basic Setting, Function 04 (2 Of 6)

Courtesy of AUDI OF AMERICA, INC.

Indicated on display:

Fig 3: V.A.G 1551 Scan Tool (ST) Display - Front Passenger Seat Adjustment With Memory Control Module, Basic Setting, Function 04 (3 Of 6)

Courtesy of AUDI OF AMERICA, INC.

Indicated on display:

Fig 4: V.A.G 1551 Scan Tool (ST) Display - Front Passenger Seat Adjustment With Memory Control Module, Basic Setting, Function 04 (4 Of 6)

Courtesy of AUDI OF AMERICA, INC.

Indicated on display:

Fig 5: V.A.G 1551 Scan Tool (ST) Display - Front Passenger Seat Adjustment With Memory Control Module, Basic Setting, Function 04 (5 Of 6)

Courtesy of AUDI OF AMERICA, INC.

Indicated on display:

Fig 6: V.A.G 1551 Scan Tool (ST) Display - Front Passenger Seat Adjustment With Memory Control Module, Basic Setting, Function 04 (6 Of 6)

Courtesy of AUDI OF AMERICA, INC.

Then check display value 4 in measuring value block 002. Display must show mean counter value (32767).
Check basic setting as follows:
Move seat backrest to rear as far as it will go.
Press memory button and one of the personalized buttons (e. g. memory position 1).
Then press memory position button selected above (for example, 1) again with driver's door open. Backrest moves to rear stop, leaving a safety clearance with respect to rear seat bench (leg room for rear passenger).
