Camber Adjustment (Rear): AWD

Before checkingalignment, read PRELIMINARY CHECKS  and WHEEL ALIGNMENT WORK SEQUENCE  .

Loosen eccentric adjusting nut located in the lower rear control arm. See Fig 1 . Adjust camber by turning eccentric bolt. The maximum adjustment range is 90 degrees to the left or right of the center position. Tighten eccentric nut to 70 ft. lbs. (90 N.m). Recheck rear camber.

Fig 1: Adjusting Rear Camber (AWD)

Courtesy of AUDI OF AMERICA, INC.
