Water Pump
Water pump is driven by timing belt and is mounted at lower left front of engine block. To remove, drain cooling system and remove timing belt cover. Loosen and remove water pump mounting bolts. Remove pump and check for wear. To install, use new "O" ring and reverse removal procedure. Add coolant mixture until tank is full and replace cap. Run engine until cooling fan turns on. Check coolant level and top off if necessary.
