Steering Columns: Overhaul

Remove stop washer from top end of column, then remove plain washers, spring, and support. Slide column down into tube in order to gain access to column bearing.

NOTE: After column is reassembled and installed, check for proper operation of lock mechanism BEFORE shearing heads of lock mounting screws.
Fig 1: Audi WO Steering Column Assembly
G09346119Courtesy of AUDI OF AMERICA, LLC
