Strut Brace Replacement

  1. Remove the cowl cover (see FRONT BULKHEAD BRACE COVER REPLACEMENT ).
  2. Disconnect the brake booster vacuum hose (A) from the strut brace (B).
    Fig 1: Brake Booster Vacuum Hose And Strut Brace With Torque Specifications
    G08070920Courtesy of AMERICAN HONDA MOTOR CO., INC.
  3. Remove the bolts and the nuts from the top of the damper, and remove the strut brace.
  4. Install the strut brace in the reverse order of removal.
