Ambient Light Test

WARNING: This page is about a different car, the 2008 Acura TL and 2007 Acura TL. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the roof console and disconnect the 20P connector (see INTERIOR LIGHT SWITCH TEST/REPLACEMENT  ).
  2. Connect the roof console connector terminal No. 3 to battery power and terminal No. 7 to body ground. The ambient lights (A) should turn on. If they do not turn on, replace the roof console.
    Fig 1: Identifying Ambient Lights
    G05462730Courtesy of AMERICAN HONDA MOTOR CO., INC.
