VSA Modulator - Control Unit Removal and Installation: Removal

  1. Pull up the lock (A) of the VSA modulator-control unit 47P connector (B), and the connector disconnects itself.
    Fig 1: Pulling Up Lock Of VSA Modulator-Control Unit 47P Connector
    G03661416Courtesy of AMERICAN HONDA MOTOR CO., INC.
  2. Disconnect the six brake lines from the VSA modulator-control unit (C).
  3. Remove the three 6 mm bolts, then remove the VSA modulator-control unit with bracket (D) from the body.
  4. Remove the two 6 mm bolts and the hex bolt, then remove the VSA modulator-control unit from the bracket.
