VSA Modulator/Control Unit: Removal

Disconnect pressure sensor 3-pin connector from modulator/control unit. See Figure and Figure . Pull up 42-pin connector locking lever, then unplug 42-pin connector. Disconnect 6 brake lines. Remove 2 mounting nuts, then remove modulator/control unit.
