DTC P1121

The scan tool indicates Diagnostic Trouble Code (DTC) P1121: Throttle Position (TP) lower than expected.

Fig 1: Diagnostic Trouble Code (P0121) - Flow Chart
G06287959Courtesy of AMERICAN HONDA MOTOR CO., INC.
