Home >> Mitsubishi >> 2010 >> Lancer ES, Standard >> Repair and Diagnosis >> Electrical >> Starter >> Starting System -- Lancer >> Starter Motor Assembly >> Disassembly And Assembly >> Notes

Disassembly And Assembly: Notes

Fig 1: Exploded View Of Charging System Components With Torque Specifications
G06671922Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
