Speed Control Disengage Switch
Adjust brake pedal height. Measure distance between brake pedal stopper and threaded end of disengage switch. Distance should be .012-.040" (0.3-1.0 mm). To adjust, loosen switch lock nut. Adjust switch until height is correct. Tighten lock nut.
